R3132 Series Spectrum Analyzer Operation Manual
4.2.9 GPIB Command Codes
4-39
Table 4-14Power (2 of 3)
Function Listener Code
Talker Request
Code Output Format
Parameter setup
Default
Manual
Define → Default
OBWST USR
OBWST MNL
OBWST DEF
OBWST? 0:(Unused)
1:Default
2:Manual
ACP Execution
ACP OFF
ACP [ON]
ACP OFF
ACPON? 0:OFF
1:ON
ACP measurement value ––– ACP? n<DLM> f1L,l1L,
f1H,l1H<DLM>...(*1)
Reference power value ––– ACPREF? Level
BS Window ON
OFF
ACPBSW ON
ACPBSW OFF
ACPBSW? 0:OFF
1:ON
ACP real-time execution ACPEXE ––– –––
Carrier Bandwidth CARRBS * CARRBS ? Frequency
CS/BS table input
erase
CSBSIN *,*
CSBSDEL
–––
–––
–––
–––
ACP screen FULL
SEPA
CARRIER
ACPSCR FULL
ACPSCR SEPA
ACPSCR CARR
ACPSCR? 0:1 screen
1:Separate screen
2:1 screen (Carrier measurement)
Symbol Rate 1/T SYMRT * SYMRT? Frequency
Roll Off Factor RFACT * RFACT? Real number
√Nyquist filter ON
OFF
NQST ON
NQST OFF
NQST? 0:OFF
1:ON
Graph ON
OFF
ADG [ON]
ADG OFF
ADG? 0:OFF
1:ON
Parameter setup
Default
Manual
Define → Default
ACPST USR
ACPST MNL
ACPST DEF
ACPST? 0:(Unused)
1:Default
2:Manual
Spectrum mask execution
Spectrum mask OFF
SPM [ON]
SPM OFF
SPMON? 0:OFF
1:ON
Parameter setup
Default
Manual
Define → Default
SPMST USR
SPMST MNL
SPMST DEF
SPMST? 0:(Unused)
1:Default
2:Manual
Spectrum mask result ––– SPM? ref<DLM>n<DLM>f1L,l1L,
f1H,l1H<DLM>…(*2)
(*1) n = Number of points
fnL= nth frequency (time) Low
lnL= nth level Low
fnH= nth frequency (time) High
lnH= nth level High
<DLM> = Delimiter
(*2) ref = Reference power value
n = Number of points
fnL= nth frequency (time) Low
lnL= nth level Low
fnH= nth frequency (time) High
lnH= nth level High
<DLM> = Delimiter
To Next Page
