4.2.9 GPIB Command Codes
4-28
Table 4-6 Trace (1 of 2)
Function Listener Code
Talker Request
Code Output Format
Trace A ––– TA? HI LOW
0: 0: Write
1:NORM 1: View
2:A-DL→A2: Blank
3:A-B→A3: Max Hold
4:B-A→A 4: Min Hold
5: 5: Averaging
6: 6: Power AVG
A write AW ––– –––
A view AV ––– –––
A blank AB ––– –––
A max hold
A max hold OFF
AMAX ON
AMAX OFF
AMAX? 0:OFF
1:ON
A min hold
A min hold OFF
AMIN ON
AMIN OFF
AMIN? 0:OFF
1:ON
A Averaging times
Start
Stop
Pause
Continue
1 time
continuous
SWPCNT *
AG *
AAVG ON
AGR
AAVG OFF
AGS
AGP
AGC
AGSGL
AGCNT
SWPCNT?
AG?
AAVG?
AGP?
AGSGL?
Average times
Average times
0:OFF
1:ON
0:Continue
1:Pause
0:Continuous
1:1 time
Power Average AON
OFF
Pause
Continue
1 time
continuous
APAVG ON
APAVG OFF
AGP
AGC
AGSGL
AGCNT
APAVG?
AGP?
AGSGL?
0: OFF
1: ON
0: Continue
1: Pause
0: Continuous
1: 1 time
Math A A-B→A
B-A→A
A-DL→A
ABA
BAA
ADLA
–––
–––
–––
–––
–––
–––
Trace B ––– TB? 0:Write
1:View
2:Blank
3:Max Hold
4:Min Hold
5:Averaging
6: Power AVG
B write BW ––– –––
B view BV ––– –––
B blank BB ––– –––
B max hold
B max hold OFF
BMAX ON
BMAX OFF
BMAX? 0:OFF
1:ON
