5.2.14 Accuracy of Frequency Readout and Count Frequency Marker
5-51
5.2.14 Accuracy of Frequency Readout and Count Frequency Marker
The accuracy of the spectrum analyzer frequency readout and count frequency marker is tested with an
input signal of known frequency.
For the points of frequencies above 5 GHz are required to tune preselector peak.
Specification:
Accuracy of Frequency Readout
±(Center Frequency × Frequency Reference Accuracy+ Frequency span × Frequency Span Accu-
racy + 0.15 × Resolution band width + 60 Hz)
Span Accuracy
±1% of Span
Accuracy of Frequency Counter Marker (Span < 200 MHz, S/N > 25 dB)
±(Marker Frequency × Frequency Reference Accuracy + 1 LSD)
Instruments Required:
Procedures:
Setting the measurement conditions
1. Connect the signal generator and the frequency standard as shown Figure 5-14.
Instruments Qty. Recommended Model
Signal Generator 1 SMP04
Frequency Standard 1 R3031
Minimum Loss Pad 1
*1
HP11852B
RF Cable BNC(m)-BNC(m) 1 MI-09
RF Cable SMA(m)-SMA(m) 3 A01002
RF Cable K(m)-K(m) 1
*2
Adapter N(m)-SMA(f) 2
Adapter K(f)-K(f) 1
*2
*1 R3132N Only
*2 R3182 Only
