R3132 Series Spectrum Analyzer Operation Manual
5.2.18 Third Order Intermodulation Distortion
5-73
Instruments Required:
Procedures:
Initializing the power meter and the sensor
1. On the power meter, perform the zeroing and calibration with power sensor.
2. On the power meter, set the unit into dBm mode, after calibration has done.
3. On the power meter, set the correction frequency to 200 MHz.
Setting the measurement conditions (Frequency 200 MHz)
4. Connect the power sensor to power divider output.
Instruments
Qty.
Recommended Model
Signal Generator 1 SMP02
Signal Generator 1 SMP04
Power Meter 1 NRVS
Power Sensor 1 NRV-Z55
Power Divider 1 DDUL-20A-1000
Power Divider 1 DDUL-20A-10G
Minimum Loss Pad 1
*1
HP11852B
RF Cable SMA(m)-SMA(m) 3 A01002
Adapter N(m)-SMA(f) 2
Adapter SMA(f)-SMA(f) 1
*2
*1 R3132N Only
*2 R3182 Only
