R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-120
(1) Frequency Reference Output Accuracy
(2) Calibration Signal Amplitude Accuracy
(3) Displayed Average Noise Level
Test Data
Specification Result
Min. (Hz)
Measured
Value
Max. (Hz) Pass/Fail
30 MHz 29.99994 30.00006
30 MHz (OPT20) 29.999997 30.000003
Test Data
Specification Result
Min. (Hz)
Measured
Value
Max. (Hz) Pass/Fail
-20 dBm -20.3 -19.7
Test Data
Center Frequency
(MHz)
Specification Result
Preamplifier Min. (dBm)
Measured Value
(dBm)
Max. (dBm) Pass/Fail
OFF 10.1 N/A -117.0
101 N/A -116.8
501 N/A -116.0
1001 N/A -115.0
1501 N/A -114.0
2001 N/A -113.0
2999 N/A -111.0
ON 1 N/A -132.0
10.1 N/A -132.0
101 N/A -131.7
501 N/A -130.5
1001 N/A -129.0
1501 N/A -127.5
2001 N/A -126.0
2999 N/A -123.0
