R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-123
(5) Resolution Bandwidth Accuracy and Selectivity
• Resolution Bandwidth Accuracy
• Resolution Bandwidth Selectivity
Test Data Specification Result
RBW (Hz) Span Setting (Hz) Min. (Hz)
Measured Value
(Hz)
Max. (Hz) Pass/Fail
3 M 5 M 2.25 M 3.75 M
1 M 2 M 0.8 M 1.2 M
300 k 500 k 240 k 360 k
100 k 200 k 80 k 120 k
30 k 50 k 24 k 36 k
10 k 20 k 8 k 12 k
3 k 5 k 2.4 k 3.6 k
1 k 2 k 0.8 k 1.2 k
300 (OPT27) 1 k 240 360
100 (OPT27) 1 k 80 120
30 (OPT27) 1 k 24 36
Test Data
Measured Value
(Hz)
Specification Result
RBW (Hz)
Span Setting
(Hz)
60 dB 3 dB Min. Actual Max.
Pass/
Fail
3 M 25 M N/A 15
1 M 20 M N/A 15
300 k 5 M N/A 15
100 k 2 M N/A 15
30 k 500 k N/A 15
10 k 200 k N/A 15
3 k 50 k N/A 15
1 k 20 k N/A 15
