R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-134
• Frequency Counter Accuracy
(14) Second Harmonic Distortion
Center Frequency
(GHz)
Frequency
Span
(MHz)
Specification Result
Min. (GHz)
Measured
Value (GHz)
Max. (GHz) Pass/Fail
2 1 1.999995999 2.000004001
Apply for R3162/72/82
5 1 4.999989999 5.000010001
Apply for R3172/82
11 1 10.999977999 11.000022001
18 1 17.999963999 18.000036001
Apply for R3182
35 1 34.999929999 35.000070001
Test Data Specification Result
Fundamental
Frequency (GHz)
Second Harmonic
Frequency (GHz)
Min.
(dBc)
Measured Value
(dBc)
Max.
(dBc)
Pass/Fail
1.5 3.0 N/A -80
1.9 3.8 N/A -80
To Next Page
