6.2.2 Performance Verification Test Record Sheets
6-22
6.2.2 Performance Verification Test Record Sheets
Performance Verification Test Record Sheets
Model: OPT3172/3182+17 Date:
Serial Number:
1. Noise Level
2. Frequency Response
Test Data Specification Result
Frequency
(GHz)
Min. (dBm)
Measured value
(dBm)
Max. (dBm) Pass/Fail
40.5 NA -93
50.0 NA -93
50.5 NA -93
51.0 NA -93
51.5 NA -93
52.0 NA -93
52.5 NA -93
53.0 NA -93
53.5 NA -93
54.0 NA -93
54.5 NA -93
55.0 NA -93
60.0 NA -93
Test Data Specification Result
Frequency
(GHz)
Calibrated
value (dBm)
Measured value
(dBm)
Min. (dB)
Actual value
(dB)
Max. (dB) Pass/Fail
40.0 -5 +5
40.1 -5 +5
40.2 -5 +5
40.3 -5 +5
40.4 -5 +5
40.5 -5 +5
40.6 -5 +5
40.7 -5 +5
40.8 -5 +5
40.9 -5 +5
41.0 -5 +5
41.1 -5 +5
