ADVANTEST R3132 Series

R3132 Series Spectrum Analyzer Operation Manual
7.2 R3132N Specifications
7-8
(6) Input and Output
(7) General Specifications
Characteristics Specification
RF input
Connector
Impedance
VSWR / Preamplifier OFF
VSWR / Preamplifier ON
N type
75Ω (nominal)
< 1.5 : 1 (100 kHz to 2.2 GHz) (characteristic value)
with input attenuator. 10 dB to 50 dB
< 2 : 1 (9 kHz to 2.2 GHz) (characteristic value)
with input attenuator. 5 dB to 50 dB
< 2.5 : 1 (9 kHz to 2.2 GHz) (characteristic value)
Probe power ±12 V (nominal), 4-pin connector
Calibration output signal BNC female, 75Ω (nominal)
30 MHz, -20 dBm
10MHz reference input BNC female, 500Ω (nominal)
-10 dBm to +10 dBm
External trigger input BNC female
Phone output Small size monophonic female
GPIB interface IEEE-488 bus connector
Serial interface D-Sub 9pins
Printer interface D-Sub 25pins, ESC/P, ESC/P-R, PCL
Video output VGA (15 pins, female)
Floppy drive 3.5 inch, MS-DOS format
Characteristics Specification
Operating environment range 0°C to +50°C
Relative humidity 85% or less (without condensation)
Storage environment range -20°C to +60°C, Relative humidity 85% or less
AC input power source Automatic switching to 100 VAC or 200 VAC
For 100 VAC: 100 to 120 VAC, 50 to 60 Hz
For 200 VAC: 220 to 240 VAC, 50 to 60 Hz
Power consumption < 200 VA
Mass < 14kg
Dimensions Approximately 424(W) × 177(H) × 300(D) mm
(not including projections such as rubber feet and connectors)
