ADVANTEST R3132 Series

R3132 Series Spectrum Analyzer Operation Manual
7.4 R3172 Specifications
7-16
(4) Dynamic Range
*1 For a temperature range of 20°C to 30°C. Add 2 dB for a temperature range of 0°C to 50°C.
Characteristics Specification
Displayed Average Noise Level
Preamplifier OFF
Preamplifier ON
with RBW 1 kHz, VBW 10 Hz and input attenuator 0 dB, f ≥ 10 MHz
10 MHz to 3.3 GHz (band0) : -117 dBm + 2f (GHz)dB *1
3.2 GHz to 7.1 GHz (band1) : -112 dBm *1
7 GHz to 14.7 GHz (band2) : -111 dBm *1
14.5 GHz to 22 GHz (band3) : -107 dBm *1
22 GHz to 26.5GHz (band3) : -104 dBm *1
1 MHz to 3.3 GHz : -132 dBm + 3f (GHz)dB
Gain compression (1 dB)
Preamplifier OFF
Preamplifier ON
(Input attenuator 0 to 30dB)
200 MHz to 3.3 GHz (Band 0) : > 0 dBm (mixer input level)
3.2 GHz to 26.5 GHz (Band 1 to 3) : > -5 dBm (mixer input level)
200 MHz to 3.3 GHz (Band 0) : > -25 dBm (RF input level)
Spurious Response
Second harmonic distortion
Third order intermodulation
distortion
Image/Multiple/Out of band
response
Preamplifier OFF
≤-80 dBc (200MHz to 3.3GHz, band 0)
≤-70 dBc (3.2GHz to 26.5GHz, band 1 to 3)
(Mixer input level -30dBm, two signal difference > 50 kHz)
≤-70 dBc (10 MHz ≤ f ≤ 18 GHz)
≤-60 dBc (18 MHz < f ≤ 23 GHz)
≤-50 dBc (23 GHz < f ≤ 26.5 GHz)
Residual Responses
Preamplifier OFF
Preamplifier ON
(input terninated 50Ω, input attenuator 0 dB, f ≥ 1 MHz)
≤ -100 dBm (band 0)
≤ -90 dBm (band 1 to 3)
≤ -105 dBm (band 0)
Freq. range Mixer level Distortion level
100 MHz to 800 MHz -30 dBm ≤ -70 dBc
≥ 800 MHz (band 0) -30 dBm ≤ -80 dBc
≥ 3.3 GHz -10 dBm ≤ -100 dBc
