7.4 R3172 Specifications
7-18
(6) Input and Output
(7) General Specifications
Characteristics Specification
RF input
Connector
Impedance
VSWR
Preamplifier OFF
Preamplifier ON
N female (changeable to SMA female)
50Ω (nominal)
(at tuned frequency)
< 1.5 : 1 (9 kHz to 3.3 GHz, band 0) (characteristic value)
< 2 : 1 (3.2 GHz to 26.5 GHz, band 1-3) (characteristic value)
with input attenuator 10 dB to 70 dB
< 2.5 : 1 (9 kHz to 3.3 GHz, band 0) (characteristic value)
Probe power ±12 V (nominal), 4-pin connector
Calibration output signal BNC female, 50Ω (nominal)
30 MHz, -20 dBm
10MHz reference input BNC female, 500Ω (nominal)
-10 dBm to +10 dBm
External trigger input BNC female
Y axis output BNC female
Approximately 2 V in full scale (10 dB/div)
Phone output Small size monophonic female
GPIB interface IEEE-488 bus connector
Serial interface D-Sub 9pins
Printer interface D-Sub 25pins, ESC/P, ESC/P-R, PCL
Video output VGA (15 pins, female)
Floppy drive 3.5 inch, MS-DOS format
Characteristics Specification
Operating environment range 0°C to +50°C
Relative humidity 85% or less (without condensation)
Storage environment range -20°C to +60°C
Relative humidity 85% or less
AC input power source Automatic switching to 100 VAC or 200 VAC
For 100 VAC: 100 to 120 VAC, 50 to 60 Hz
For 200 VAC: 220 to 240 VAC, 50 to 60 Hz
Power consumption < 200 VA
Mass(without option) < 16kg
Dimensions Approximately 424(W) × 177(H) × 300(D) mm
(not including projections such as rubber feet and connectors)
