R3132 Series Spectrum Analyzer Operation Manual
7.5 R3182 Specifications
7-21
(4) Dynamic Range
*1 For a temperature range of 20°C to 30°C. Add 2 dB for a temperature range of 0°C to 50°C.
Characteristics Specification
Displayed Average Noise Level
Preamplifier OFF
Preamplifier ON
with RBW 1 kHz, VBW 10 Hz and input attenuator 0 dB, f 10 MHz
10 MHz to 3.3 GHz (band0) : -117 dBm + 2f (GHz)dB *1
3.2 GHz to 7.1 GHz (band1) : -114 dBm *1
7 GHz to 14.7 GHz (band2) : -112 dBm *1
14.5 GHz to 27 GHz (band3) : -110 dBm *1
26.5 GHz to 30 GHz (band4) : -107 dBm *1
29.5 GHz to 40 GHz (band5) : -106 dBm *1
1 MHz to 3.3 GHz : -132 dBm + 3f (GHz)dB
Gain compression (1 dB)
Preamplifier OFF
Preamplifier ON
(Input attenuator 0 to 30dB)
200 MHz to 3.3 GHz (Band 0) : > 0 dBm (mixer input level)
3.2 GHz to 40 GHz (Band 1 to 5) : >-5 dBm (mixer input level)
200 MHz to 3.3 GHz (Band 0) : > -25 dBm (RF input level)
Spurious Response
Second harmonic distortion
Third order intermodulation
distortion
Image/Multiple/Out of band
response
Preamplifier OFF
-80 dBc (200MHz to 3.3GHz, band 0)
-75 dBc (3.2GHz to 30GHz, band 1 to 4)
-70 dBc (29.5GHz to 40GHz, band 5)
(Mixer input level -30dBm, two signal difference > 50 kHz)
-70 dBc (10 MHz f18 GHz)
-65 dBc (18 GHz < f 26.5 GHz)
-60 dBc (26.5 GHz < f 34 GHz)
-50 dBc (34 GHz < f 40 GHz)
Residual Responses
Preamplifier OFF
Preamplifier ON
(input terninated 50, input attenuator 0 dB, f 1 MHz)
-100 dBm (band 0)
-90 dBm (band 1 to 5)
-105 dBm (band 0)
Freq. range Mixer level Distortion level
100 MHz to 800 MHz -30 dBm -70 dBc
800 MHz (band 0) -30 dBm -80 dBc
3.3 GHz -10 dBm -95 dBc
