R3132 Series Spectrum Analyzer Operation Manual
7.5 R3182 Specifications
7-23
(6) Input and Output
Characteristics Specification
RF input
Connector
Impedance
VSWR
Preamplifier OFF
Preamplifier ON
K male
50Ω (nominal)
(at tuned frequency)
< 1.5 : 1 (9 kHz to 3.3 GHz, band 0) (characteristic value)
< 2 : 1 (3.2 GHz to 27 GHz, band 1-3) (characteristic value)
< 2.2 : 1 (26.5 GHz to 40 GHz, band 4-5) (characteristic value)
with input attenuator 10 dB to 70 dB
< 2.5 : 1 (9 kHz to 3.3 GHz, band 0) (characteristic value)
Probe power ±12 V (nominal), 4-pin connector
Calibration output signal BNC female, 50Ω (nominal)
30 MHz, -20 dBm
Ext. Mixer local Out
Connector
Impedance
Frequency range
Output level
SMA female
50Ω (nominal)
4.0 GHz to 7.6 GHz
> +8dBm
10MHz reference input BNC female, 500Ω (nominal)
-10 dBm to +10 dBm
External trigger input BNC female
Y axis output BNC female
Approximately 2 V in full scale (10 dB/div)
Phone output Small size monophonic female
GPIB interface IEEE-488 bus connector
Serial interface D-Sub 9pins
Printer interface D-Sub 25pins, ESC/P, ESC/P-R, PCL
Video output VGA (15 pins, female)
Floppy drive 3.5 inch, MS-DOS format
