9. Technical data
CAUTION: All technical specifications should be updated based on the real state of
Aeon8800A Anaesthetic Workstation; no notification will be made if any change
happens.
CAUTION: All display values are measured under dry environment and proper
pressure.
WARNING: Cylinder valve should be closed during pipeline gas supply, so that gas
shortage can be avoided due to exhausted gas supply or pipeline problems.
9.1. Schematic diagram of gas circuit system
Pneumatic system plays the role of supplying O
2
, N
2
O, AIR and anaesthetic agent to breathing
system, ensuring their pressures are within normal range respectively, so that normal operation of
the Anaesthetic Workstation and patient’s safety can be guaranteed.
