9.Technical data
143
in order to be accordance with standards.
APL valve resistance
Flow speed:3L/min, flow resistance: 0.05～3kPa
Flow speed:30L/min, flow resistance: 0.1～0.5kPa
Connector leak
（APL valve close）leak volume≤50ml/min
Check valve resistance
In dry environment: ≤0.15kPa
Pressure generated from
moist check valve
<0.14kPa
Pressure of opening moist
check valve
<0.1kPa
System compliance
45mL/kPa (for standard breathing tube)
Interior capacity
3.9L±0.1L
O
2
flush
25～75L/min
O
2
supply failure alarm
<200kPa
O
2
concentration
Not less than 19%
Safety valve
Open pressure is 11 ± 1kPa，the flow is 5L/min.
9.7.1. Compliance correction
In all of software version, the Anaesthetic Workstation is able to carry out a compliance correction
which compensates for volume "lost" in hoses and in the breathing system.
The Anaesthetic Workstation determines the system compliance (hoses and breathing system)
and required later for compliance correction during the self-test or standby leak test. The hose of
standard equipped compliance has a fixed value of 11mL/kPa.
The V
T
set is delivered during the first breath.
ΔP is calculated from end-expiratory pressure (P1) and end-inspiratory pressure (P2).
Csys: the system compliance.
