Aeonmed Aeon8800A - Connection of O 2 Sensor

48
4.1.4. Connection of O
2
sensor
First step:
Pull out the O2 cell plug from the inspiratory valve
cover and then put the O2 cell plug into the hole on
the bottom of the breathing system integration.
Second step:
Connect the transparent joint which connects the O
2
sensor by cable to the top port of the O
2
sensor.
