3.User interface
37
Name description
Diagram
on the right. If the NET connection is not detected, this indicator
should not be displayed.
Anaesthesia
NOTE: The function of the interface is to transmit the data to
other receiving terminal through Ethernet cable according
to HL7 protocol.
3.2.5. Waveform display area
Waveform display area is in the center of the screen, including waveform and breathing loop.
Waveform name
Diagram
Pressure-time waveform (Paw-t)
Velocity-time waveform (Flow-t)
Tidal volume - time waveform (VT-t)
Carbon dioxide-time waveform (CO
2
-t)
