Aeonmed Aeon8800A - Gas Dynamics; Monitor Performance

148
9.8.3. Gas dynamics
Table 9-12 gas dynamics
Gas source
Anaesthetic system
Gas component
O
2
Rating supply pressure
400kPa
Inlet pressure range
280～600kPa
Flow valve range
5～75L/min
Output
1
Pressure range: 0～11kPa；Flow range: 0～75L/min
Label 1: Within rated outlet pressure range and under double maximum rated inlet pressure
condition.
According to ISO 80601-2-13, test shall be carried under peak flow 60L/min, fresh gas 10L/min.
Table 9-13 resistance
Item
Standard Requirement
Test Result
Expiratory resistance under
manual condition
<0.6kPa
0.51
Inspiratory resistance under
manual condition
<0.6kPa
0.39
Expiratory resistance under
automatic condition
<0.6kPa
0.57
Inspiratory resistance under
automatic condition
<0.6kPa
0.22
9.8.4. Monitor performance
Table 9-14 monitor performance
Item
Range
Stepping
Accuracy
V
t
0～3000mL
1mL
0～20mL, error is ±10mL;
20～100mL, error is ±15% or ±10mL, choose
the maximum one; 100～1500mL, error is
±15%
MV
0～30L/min
0.1L/min
0L/min～20L/min，error is ±15% or ±1L/min，
choose the maximum one
Freq.
0～110bpm
1bpm
0-100bpm, error is 1bpm or ±15%, choose
the maximum one;
