Aeonmed Aeon8800A - Connection of the Anaesthetic Gas;Co Monitoring Module (Optional)

4.Pre-operative preparation
49
Third step:
Connect the O
2
sensor with the inspiratory valve
cover.
Fourth step:
Connect the other end of the O
2
sensor connecting
cable to the port marked “Oxygen” of the outlet
module.
4.1.5. Connection of the anaesthetic gas/CO
2
monitoring module (optional)
CAUTION: The anaesthetic gas/CO
2
monitoring module has mainstream and
sidestream. The two types can’t be used at the same time.
CAUTION: The anaesthetic gas/CO
2
monitoring module conforms to ISO 80601-2-55.
CAUTION: Please refer to the IRMA CO
2
/AX+ user guide, who is delivered together with
the IRMA CO
2
/AX+ sensor and include all the information about operations and
technical specifications of these two products.
