50
4.1.5.1. Connection of the mainstream monitoring module
Step 1:
Snap the probe on top of the Airway adapter. It
will click into place when properly seated.
Step 2: Connect the RS232 interface of the
adapter to the RS232 interface on the back of the
user interface.
Step 3:
CAUTION: After powering on the system, a
green LED indicates that the probe is ready
for use.
Connect the smaller end of the adapter to the
Y-piece connector.
