3.23.7 Secure the Side Lower Hopper Cloth Frame and Uprights to the Hopper
Important
Secure the side frame and upright on one side before moving to the other.
Secure the Side Lower Hopper Cloth Frame to the Hopper
Note
Finger-tighten the bolts only.
1. Pull the cloth tight on one side until the cloth (2) lays smoothly and then slide the lower frame along the
pocket until the holes in the frame align with the holes in the hopper (5).
Note
Ensure the cloth is fully stretched out and the upright frame can also be secured from this position
2. Starting in the middle, drill a hole in the cloth through the lower hopper cloth frame, flashing (3) , urethane
seal (4), and hopper.
Note
Ensure that the urethane seal does not slip below the bolt.
3. Insert and finger-tighten the bolt (1,6).
4. Repeat steps 3 and 4, working out from the middle bolt until the side is secured to the hopper
Item
Description
1
1/4" x 1-3/4" Elevator Bolt (GR 2)
2
Hopper Cloth (with frame inserted)
3
Flashing
4
Seal
5
Hopper Weldment
6
1/4" Hex Bolt
FIELD LOADER S-DRIVE – PORTABLE GRAIN BELT CONVEYOR 3. ASSEMBLY
