AGI BCX3 1549 - Install the Side Frames

8210-00020 R1 49
3.19.2 Install the Side Frames
Item
Description
1
Left Side Frame
2
Right Side Frame
3
1/2" X 2–1/2" Hex Bolt (GR 8)
4
1/2" Hex Flange Nut
Hardware: HRDW-15–102
1
2
4
3
Hopper
FIELD LOADER S-DRIVE – PORTABLE GRAIN BELT CONVEYOR 3. ASSEMBLY
