3.42. Install the Manual Container
1. Position the manual container (1) on the axle arm.
2. Secure the container with two self-tapping screws (2).
Figure 89. Screw-on Manual Container
Item
Description
1
Manual Container
2
Self-Tapping Screw #14 x 5/8"
1
3
1
2
