3.23. Install the Collapsible Hopper Cloth
Installing the collapsible hopper cloth requires the completion of the following tasks:
Step
Description
1
Install the Hopper Springs
2
Assemble and Install the Upper Hopper Cloth Frame
3
Secure the Upper Hopper Cloth Frame to the Hopper
4
Straighten the Seals and Position the Flashing
5
Insert the Lower Hopper Cloth Frame into the Hopper Cloth
6
Secure the Front Lower Hopper Cloth Frame to the Hopper
7
Secure the Side Lower Hopper Cloth Frame and Uprights to the Hopper
8
Tighten the Lower Hopper Cloth Frame Bolts
9
Install the Split Loom
Finished Collapsible Hopper Cloth
