3.24. Attach the Hopper Underside Covers
Table 13. Underside Covers
Item
Description
1 Hopper Front Cover
2 Spring Pin
3 Hopper Bottom Cover
Figure 42. Installing the Underside Front Cover
1
2
Figure 43. Installing the Underside Main Cover
3
