AGI BCX3 1549 - Specifications

8210-00020 R1 157
5. Specifications
Specifications
Table 36. 1549 CX
3
Field Loader
MODEL 1549 CX
3
DIMENSIONS
Conveyor Tube Diameter
10"
Belt Length
110'8"
OTHER
Gas Drive (HP)
32
Gear Box Oil Type
80W90 or SAE Approved Equivalent
Hydraulic Oil ATF Dexron III or Equivalent
Hitch Pin Size (Min. Diameter x Length)
1/2" x 3"
FIELD LOADER S-DRIVE – PORTABLE GRAIN BELT CONVEYOR 5. SPECIFICATIONS
