156 8210-00020 R1
Table 34 Stud End O-Ring Boss (ORB) SAE (U/UF) – Carbon Steel (continued)
Tube Size Thread UNF-2A Max ft-lbs
Max N-m
-6
9/16" - 18
22-24 29-33
-8
3/4" - 16
40-43 49-53
-10
7/8" - 14
43-48 59-64
-12
1 1'16" - 12
68-75 93-102
-14
1 3/16" - 12
90-99 122-134
-16
1 5/16" - 12
112-123 151-166
-20
1 5/8" - 12
146-161 198-218
-24
1 7/8" - 12
154-170 209-231
Table 35. JIC 37° Flare Tube Fitting (J/JFS)
Tube Size Thread UNF-2A Torque ft-lbs
Torque N-m
-2
5/16 - 24
6-7 8-9
-3
3/8 - 24
8-9 11-12
-4
7/16 - 20
11-12 15-16
-5
1/2 - 20
14-15 19-21
-6
9/16 - 18
18-20 24-28
-8
3/4 - 16
36-39 49-53
-10
7/8 - 14
57-63 77-85
-12
1 1/16 - 12
79-88 107-119
-14
1 3/16 - 12
94-103 127-140
-16
1 5/16 - 12
108-113 147-154
-20
1 5/8 - 12
127-133 172-181
-24
1 7/8 - 12
158-167 215-226
-32
2 1/2 - 12
245-258 332-350
4. APPENDIX FIELD LOADER S-DRIVE – PORTABLE GRAIN BELT CONVEYOR
