8210-00020 R1 11
1.8. Hand Winch Safety
When Equipped:
• Inspect lift cable before using. Replace if frayed or damaged. Make sure lift cable is seated
and tracking properly and cable clamps are secure.
• Tighten brake lock by turning winch handle clockwise at least two clicks after lowering the
conveyor.
• Lower the conveyor fully before towing, then rotate winch handle until cable has light
tension.
• Do not lubricate winch brake discs.
1.9. Hydraulic Winch Safety
When Equipped:
• Keep away from rotating cable drum and winch cable. Do not touch or grab cable while
winch is being operated or use hands to guide the cable.
• Inspect cable and cable clamps before using hydraulic winch. Replace cable if frayed or
damaged. Tighten cable clamps if necessary.
• Check the cable anchor on the winch drum is tight.
• Confirm hydraulic hoses are in good condition.
• Do not continue to supply power to hydraulic winch after the conveyor has reached full up
position.
• Do not disconnect hydraulic quick couplers when lines are pressurized.
• Make sure lift cable is seated properly.
• Always keep a minimum of 3 cable wraps on the cable drum.
FIELD LOADER S-DRIVE – PORTABLE GRAIN BELT CONVEYOR 1. SAFETY
