3.19.3 Install the Bottom Frame
Item
Description
1
1/2" X 1" Hex Bolt (GR 8)
2
1/2" Lock Nut
3
1/2" X 1–1/4" Hex Bolt (GR 8)
Hardware: HRDW-15–132, HRDW-15–134
2
1
2
1
3. ASSEMBLY FIELD LOADER S-DRIVE – PORTABLE GRAIN BELT CONVEYOR
