3.3. Required Tools
• 2–3
pipe stand(s)
• 1
tape measure(s)
(100’ [30.5 m])
• 2
sawhorse(s)
(1200 lb [544.3 kg])
• 1
ratchet strap
• 1
standard socket set(s)
• 2
C-clamp(s) or vise grip(s)
• 2
wrench set(s)
• 1
fish tape
(100’ [30.5 m])
• 1
torque wrench(es)
• 1 tire pressure gauge
• 1
set(s) of Allen wrenches
• 1
tire chuck
• 1
hammer and punch
• 1
propane torch
• 1
drill with bits
3/16”, 5/16”
• 1
picker
with minimum reach of 12’ (3.7 m) and
4000 lb to 6000 lb (1814 kg to 2722 kg)
lifting capacity
• 2
tape measure(s)
(25’ [7.6 m])
• 1
small engine throttle wire Z bender
3.4. Before You Begin
Before you assemble the conveyor:
• Familiarize yourself with all the sub-assemblies, components, and hardware that make up the equipment.
• Have all parts and components on hand, and arrange them for easy access.
• Separate the hardware (bolts, nuts, etc.) and lay them out into groups for easier identification during
assembly.
• Ensure there is adequate space to remove the assembled conveyor from the assembly area.
3.5. Hydraulic Fittings and Bolt Tightening
Remember the following basic considerations when tightening hydraulic fittings and bolts:
• Tighten all fasteners to the torque specified in Section 4.1 – Bolt Torque on page 154. Do not replace or
substitute bolts, nuts, or other hardware that is of lesser quality than the hardware supplied by the
manufacturer.
• All hydraulic fittings should be torqued to the recommended specifications. See Section 4.2 – Fittings Torque
Values on page 155.
Do not over-tighten fittings. Over-tightening hose fittings can crack the fittings or motor body
and will void the warranty.
