150 8210-00020 R1
3.40. Install the Choke
Note
This procedure applies to carbureted engines only.
1. Bolt the mount bracket on the upper axle arm.
2. Mount the choke with extended cable onto the bracket, using a 3/8” flat washer and the nut that comes
with the choke.
3. Detach the choke that came with the motor and replace it with the other end of the choke from step 2.
Item
Description
1
Choke Mount Bracket
2
3/8" Flat Washer
3
Choke with Extended Cable
4
1/4" Lock Nut
5
1/4" Flat Washer
6
1/4" X 4" Carriage Bolt (GR 8)
3. ASSEMBLY FIELD LOADER S-DRIVE – PORTABLE GRAIN BELT CONVEYOR
