8210-00020 R1 141
3.38. Install the Gas Drive Control Box
Note
Install control box after connecting mover kit to the conveyor (refer to Mover Kit manual 8210-00021).
Figure 80. Control Box
Item
Description
1
Control Box
2
#8 x 3/4" Flat Head Screw
3
Control Box Mount (Welded to the Control Stand)
Hardware Kit: HRDW-15-107
FIELD LOADER S-DRIVE – PORTABLE GRAIN BELT CONVEYOR 3. ASSEMBLY
