AGI BCX3 1549 - Page 65

To Next Page

To Previous Page

8210-00020 R1 65

Installing the Side Guard

Item

Description

1/2" X 3" Pin

2 Hair Pin

Side Guard

1/2" Lock Nut

1/2" X 3–1/2" Hex Bolt (GR 8)

Hardware: HRDW-15–103
