Agilent Technologies 1290 Infinity II 2D-LC User Manual

4Installation
Hardware Installation
2D-LC User Guide 66
Recommended Stack Setups
InfinityLab 2D-LC Solutions allow three basic stack setups in three variations
depending on the column compartment concept that is used. The pumps used
for the first and second dimension distinguish the basic stack configurations. In
the second dimension, a 1290 Infinity or 1290 Infinity II High-Speed Pump is
mandatory. Agilent 1290 Infinity pumps are always based on the bottom. The
capillary kit covers all recommended configurations. The following
configurations optimize the system flow path, ensuring minimum delay and
dispersion volumes:
Table 8 Supported instrument configurations with a list of supported LC pumps. Numbers
refer to the stack setup that is recommended.
#
1
D pump supported
2
D pumps
1 1290 Infinity II / 1260 Infinity II Prime LC
1260 Infinity II Flexible Pump (G7104C)
Agilent 1260 Infinity II Bio Flexible Pump (G7131C)
1290 Infinity II Flexible Pump (G7104A)
Agilent 1290 Infinity II Bio Flexible Pump (G7131A)
1290 Infinity II High-Speed Pump (G7120A)
Agilent 1290 Infinity II Bio High-Speed Pump (G7132A)
1290 Infinity / 1290 Infinity II
1290 Infinity II High-Speed Pump (G7120A)
Agilent 1290 Infinity II Bio High-Speed
Pump (G7132A)
1290 Infinity Binary Pump (G4220A)
See Figure 31 on page 73
2 1290 Infinity
1290 Infinity Quaternary Pump (G4204A)
1290 Infinity Binary Pump (G4220A)
1290 Infinity II
1290 Infinity II High-Speed Pump (G7120A)
See Figure 32 on page 74
3 1260 Infinity Binary / 1260 Infinity II Binary
1260 Infinity II Binary Pump (G7112B)
1260 Infinity Binary Pump (G1312B)
1290 Infinity II
1290 Infinity II High-Speed Pump (G7120A)
See Figure 33 on page 75
NOTE
This guide only covers setups that contain at least one Infinity II pump module!
Setups that contain exclusively 1200 Infinity Series modules must be installed
with the corresponding capillary kit.
Connections mentioned in this setup are the following:
• Concurrent direction for the Standard 2D-LC Valve (G4236A) with Single
Heart Cut Configuration
See Figure 28 on page 67.
• Countercurrent for the ASM 2D-LC Valve (G4243A) or Standard 2D-LC Valve
(G4236A) with a Multiple Heart-Cutting Configuration
See Figure 30 on page 71.
In the instruction table, the connections to valve port are mentioned in brackets,
for example ASM Valve (2) = ASM Valve, Port 2.
If you want to connect the 2D-LC Valve in another direction than in these
recommended 2D-LC setups, please follow the schematics shown under Valve
Topology in the 2D-LC Software Online help.
