2D-LC User Guide 83
4Installation
Hardware Installation
Figure 39 Setup F. Recommended setup for the
1
D/
2
D switching valve without
1
D detector.
Number of
Capillary
# Connection L x ID [mm] P/N Description
3b 1
1
D/
2
D Switching Valve (2) to
2
D DAD
280 x 0.12 5067-4651 Capillary ST 0.12x280
SL/SX
F1 2
1
D column to
1
D/
2
D Switching Valve (1);
2
D column to
1
D/
2
D switching valve (3)
120 x 0.12 5067-4652 Capillary ST 0.12x 120
SX/SX
F2 1
Connection
1
D/
2
D switching valve ports
(4) to (5)
90 x 0.12 5067-4649 Capillary ST 0.12x90 SX/S
F3 1 MCT/TCC to 2D-LC valve (6) / ASM
valve (4)
500 x 0.12 5500-1157 Capillary ST 0.12x500 SL/S
For all other capillaries / connections, please refer to Figure 31 on page 73, Figure 32 on page 74, and Figure 33 on page 75.
