6-60 Agilent 4155B/4156B User’s Guide Vol.2, Edition 5
Screen Organization
GRAPH/LIST Screen Group
STOP COND softkey
Select STOP COND primary softkey to display secondary softkeys for changing the
sampling parameters. This softkey is displayed only when SAMPLING is selected
in the MEASUREMENT MODE field on the CHANNELS: CHANNEL
DEFINITION screen.
To change the values on the secondary softkeys: enter number by using numeric
keys or change number by rotating rotary knob.
• STOP COND softkey
Select STOP COND secondary softkey to enable or disable the stop condition.
Selecting this softkey toggles between ENABLE and DISABLE.
• ENABLE DELAY softkey
Select ENABLE DELAY secondary softkey to change the enable delay time for
the stop condition. The present enable delay time is shown on this softkey and in
the data entry area. Then you can change the value.
• THRESHOLD softkey
Select THRESHOLD secondary softkey to change threshold value of the stop
condition. The present threshold value is shown on this softkey and in the data
entry area. Then you can change the value.
You can change the threshold value while measurement is being performed.
• EVENT TYPE softkey
Select EVENT TYPE secondary softkey to change the event type. Selecting this
softkey changes the event type in the following order:
Val>Th
® Val<Th ® |Val|>|Th| ® |Val|<|Th| ® Val>Th
• EVENT NUMBER softkey
Select EVENT NUMBER secondary softkey to change the event number of stop
condition. The present event number is shown on this softkey and in the data
entry area. Then you can change the value.
