Agilent Technologies 4155B User Manual

2-16 Agilent 4155B/4156B User’s Guide Vol.2, Edition 5
Measurement Mode
Sampling Measurement Mode
Figure 2-6 Sampling Measurement Operation Summary
PGU Output
Tim
e
Hold Time
Total Sampling Time (TOTAL SAMP. TIME)
Sampling
Interval
(TOTAL SAMP. TIME is one of the stop condition.)
Meas.
Time
Starts Sampling Stops Sampling
Trigger TriggerTrigger Trigger Trigger
Case 1. Sampling Interval > Meas. Time
SMU Output
Sampling
Interval
Sampling
Interval
PGU Output
Hold Time
Total Sampling Time (TOTAL SAMP. TIME)
Sampling
Interval
(TOTAL SAMP. TIME is one of the stop condition.)
Starts Sampling Stops Sampling
Trigger TriggerTrigger Trigger Trigger
SMU Output
Sampling
Interval
Sampling
Interval
Tim
e
Meas. Time
Case 2. Sampling Interval < Meas. Time
1
2
3
4
5
6
7
1
2
3
4
5
6
7
