The symbol state table, which displays the binary bits for each symbol at
the decision points, may be viewed and compared to other displays of the data.
EVM = 859.14 m%rms 1.4978 %pk at sym 55
MagErr = 609.17 m%rms 1.4317 %pk at sym 14
Phase Err = 623.96 mdeg 2.1174 deg pk at sym 44
Freq Err = 1.7722 Hz
IQ Offset = -66.106 dB SNR = 39.101 dB
0 001010100110 1111 01010001000010011010111110010010
48 000011110000000010000111100100000110000011010001
96 000011111011110001110111011101101010111110100110
144 000001100010111010110011100111111001010000110000
192 110000011110010101110100101111010000111111000010
240 011011110101010110100001000000000111100010111110
288 011110001110111100101111100001101111001110011101
336 000011000110110011011000001011110000010001001110
A Marker 15
.
0003
.
00000 sym
TRACE B: Ch1 16QAMMeasTime
B Mkr 998.80 m -134.74 deg3.000000 sym
1.5
-1.5
Const
300
m
/div
Averaging may be applied to
the numeric error summaries
Analyzing Digitally Demodulated Signals (Options AYA and AYH)
10 - 9
