System Connections (applies to all systems)
Connect This Output: To This Input:
Component Output Component Input
70900B LO Module LO OUT 70910A RF Module 1st LO IN
300 MHz OUT 1 70910A RF Module 300 MHz IN
300 MHz OUT 2 70911A IF Module 300 MHz IN
TUNE SPAN 70910A RF Module TUNE SPAN
70910A RF Module 321.4 MHz OUT 70911A IF Module 321.4 MHz IN
70911A IF Module WB VIDEO OUT 70911A IF Module WB VIDEO IN
321.4 MHz OUT 70911A IF Module 321.4 MHz OPT IN
VID OUT TO LO 70900B LO Module VIDEO IN
70310A Precision Reference
Module
100 MHz 70900B LO Module 100 MHz IN
10 MHz 89410A EXT REF IN
Additional connections needed when the system is configured with the 70004A display and the 70902A and 70903A IF
Modules.
70902A IF Module VIDEO OUT 70903A IF Module VIDEO IN
70903A IF Module 21.4 MHz OUT 70902A IF Module 21.4 MHz IN
VIDEO OUT 70911A IF Module NB VID IN
70910A RF Module 21.4 MHz OUT 70903A IF Module 21.4 MHz IN
Extending Analysis to 26.5 GHz with 20 MHz Information Bandwidth
16 - 12
