Measurement Features Available by Instrument Mode

Scalar Vector

Analog

Demodulation

Trigger types

Free run

yes yes yes

channel1 +

yes yes yes

channel2

yes yes yes

IF channel

no yes yes

internal source*

yes** yes yes

GPIB

yes yes yes

external

yes yes yes

Source types

yes** yes yes

random noise

yes yes yes

periodic chirp

yes yes yes

arbitrary

yes** yes yes

Average types

rms (and rms exponential)

yes yes yes

time (and time exponential)

no yes yes

peak hold

yes yes yes

* available only in conjunction with the arbitrary source and periodic chirp

** available only when optional RF source is disabled

+ available only in receiver modes of 0-10 MHz
