Alcatel-Lucent 7750 SR OS - Page 1188

VPRN Service Configuration Commands
Page 1188 7750 SR OS Services Guide
Sample Output
*A:ALA-1# show rip database
==============================================================================
RIP Route Database
==============================================================================
Destination Peer NextHop Metric Tag TTL Valid
------------------------------------------------------------------------------
180.0.0.10/32 180.1.7.15 0.0.0.0 2 0x0000 163 No
180.0.0.10/32 180.1.8.14 0.0.0.0 2 0x0000 179 No
180.0.0.14/32 180.1.8.14 0.0.0.0 1 0x0000 179 Yes
180.0.6.0/24 180.1.7.15 0.0.0.0 11 0x2002 163 No
180.0.6.0/24 180.1.8.14 0.0.0.0 11 0x2002 179 No
180.0.7.0/24 180.1.7.15 0.0.0.0 11 0x2002 163 No
180.0.7.0/24 180.1.8.14 0.0.0.0 11 0x2002 179 No
180.1.5.0/24 180.1.7.15 0.0.0.0 2 0x0000 151 Yes
180.1.5.0/24 180.1.8.14 0.0.0.0 1 0x0000 167 No
180.100.17.16/30 180.1.7.15 0.0.0.0 2 0x0000 151 No
180.100.17.16/30 180.1.8.14 0.0.0.0 2 0x0000 167 No
------------------------------------------------------------------------------
No. of Routes: 11
==============================================================================
*A:ALA-12#
neighbor
Syntax neighbor [ip-address | ip-int-name] [detail] [advertised-routes]
Context show>router>rip
Description Displays RIP neighbor interface information.
Parameters ip-address | ip-int-name — Displays information for the specified IP interface.
Default All neighbor interfaces.
advertised-routes — Displays the routes advertised to RIP neighbors. If no neighbors are specified,
then all routes advertised to all neighbors are displayed. If a specific neighbor is given then only
routes advertised to the given neighbor/interface are displayed.
Default Display RIP information.
Output Standard Show RIP Neighbor Output — The following table describes the standard command
output fields for a RIP group.
Valid
No — The route is not valid.
Yes — The route is valid.
Label Description
Label Description
Neighbor
The RIP neighbor interface name.
