NOTE: Replacing the system board removes any changes that you have made to the BIOS using the BIOS setup program.
You must make the appropriate changes again after you replace the system board.
NOTE: Before disconnecting the cables from the system board, note the location of the connectors so that you can
reconnect the cables correctly after you replace the system board.
2. Remove the left cover.
3. Remove the memory module.
4. Remove the single-graphics card.
5. Remove the M.2 2230 SSD or M.2 2280 SSD, as applicable.
6. Remove the wireless card.
7. Remove the top fan filter.
8. Remove the top cover.
9. Remove the processor liquid-cooling assembly.
10.Remove the processor.
About this task
The following image indicates the connectors on your system board.
Removing and installing Field Replaceable Units (FRUs) 133
