NOTE: To install the operating system on to your storage device, see Reinstall Windows to the Dell factory image using
recovery media in the Knowledge Base Resource at Dell Support Site.
Removing the M.2 2280 SSD
You can view the video to remove or install an SSD. For more information, see QR code for SSD video.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left cover.
About this task
NOTE: This procedure applies only to computers shipped with a M.2 2280 SSD. The M.2 SSD slots are marked as M.2 PCIe
SSD-0, M.2 PCIe SSD-1, or M.2 PCIe SSD-2 on the system board.
The following images indicate the location of the M.2 2280 SSD and provide a visual representation of the removal procedure.
Figure 60. Removing the M.2 2280 SSD
Removing and installing Customer Replaceable Units (CRUs) 75
