2. Remove the screw (#6-32) that secures the 2.5-inch hard drive cage to the chassis.
3. Remove the 2.5-inch hard drive cage from the tabs on the chassis.
4. Slide and lift the 2.5-inch hard drive cage away from the chassis.
5. Disconnect the data and power cables from the hard drive.
6. Remove the four screws (M3x5) that secure the hard drive to the hard drive cage.
NOTE: Note the orientation on the hard drive cage and the hard drive to replace it correctly.
7. Lift the hard drive out of the hard drive cage.
Installing the 2.5-inch hard drive
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
NOTE: The 2.5-inch hard drive is sold separately.
The following images indicate the location of the 2.5-inch hard drive and provide a visual representation of the installation
procedure.
Removing and installing Customer Replaceable Units (CRUs) 95
