Figure 38. Installing the front fan filter
Steps
Align and place the fan filter into the front fan filter slot.
The fan filter is held in place by magnets.
Next steps
1. Follow the procedure in After working inside your computer.
Left cover
Removing the left cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
About this task
The following images indicate the location of the left cover and provide a visual representation of the removal procedure.
56 Removing and installing Customer Replaceable Units (CRUs)
