Alienware Area-51 AAT2250 - 3.5-Inch Hard Drive; Removing the 3.5-Inch Hard Drive

3.5-inch hard drive
Removing the 3.5-inch hard drive
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the right cover.
About this task
NOTE: The 3.5-inch hard drive is sold separately.
The following images indicate the location of the 3.5-inch hard drive and provide a visual representation of the removal procedure.
Figure 84. Removing the 3.5-inch hard drive
Steps
1. Disconnect the data and power cables from the hard drive.
2. Press the release tabs on the hard drive carrier and slide the hard drive carrier out of the hard drive cage.
Removing and installing Customer Replaceable Units (CRUs) 97
