Top fan
Removing the top fan
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left cover.
3. Remove the top fan filter.
4. Remove the top cover.
About this task
The following images indicate the location of the top fan and provide a visual representation of the removal procedure.
Figure 100. Removing the top fan
114 Removing and installing Field Replaceable Units (FRUs)
