2. Replace the screw (#6-32) that secures the top fan to the fan bracket.
3. Align and place the cable onto the cable bracket.
4. Align and lock the cable cover so that it secures the cable in place.
5. Connect the top fan cable to the top fan cable connector (FAN1, FAN2, and FAN3) on the system board.
Next steps
1. Install the top cover.
2. Install the top fan filter.
3. Install the left cover.
4. Follow the procedure in After working inside your computer.
Front fan
Removing the front fan
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left cover.
3. Remove the right cover.
About this task
The following images indicate the location of the front fan and provide a visual representation of the removal procedure.
Removing and installing Field Replaceable Units (FRUs) 117
