Figure 66. Installing the coin-cell battery
Steps
Insert the coin-cell battery into the coin-cell battery slot with the positive side facing up, and snap the battery into place.
Next steps
1. Install the coin-cell battery cover.
2. Install the left cover.
3. Follow the procedure in After working inside your computer.
Wireless card
Removing the wireless card
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left cover.
About this task
The following images indicate the location of the wireless card and provide a visual representation of the removal procedure.
Removing and installing Customer Replaceable Units (CRUs) 81
