Rockwell Automation Publication 1769-UM022C-EN-P - June 2018 123

Chapter 8

Elements of a Control Application

A control application is comprised of several elements that require planning for

efficient application execution. Application elements include the following:

•Tasks

•Programs

•Routines

• Parameters and Local Tags

Topic Page

Tasks 124

Programs 128

Routines 130

Tags 131

Programming Languages 134

Add-on Instructions 135

Access the Module Object 136

System Overhead Time Slice 138
